F FAMILY

dancoo F

Packaging and transportatinon

Net weight (kg)

365

Gross weight (kg)

457

UNIT/20GP

UNIT/40GP

UNIT/40HQ

Packaging size

2270 × 840 × 1145mm

Feature

Exterior

Powder coated steel

Glass (door & rear)

Enamelled glass

Frame and table

Enamelled glass attached+laminate on birch plywood

Solid walls, roof and floor

A sandwich element of sheet metal, birch plywood, recycled acoustic foam and acoustic felt.

An anti-static and stain resistant low loop pile carpet for interior floor.

Weight

364.6

Measurements

Exterior (height, width, depth)

220 × 100 × 105cm

Interior (height, width, depth)

200 × 80 × 101cm

Door (height, width)

220 × 100cm

Table(width, depth，height)

65×30×16cm

Electric sockets are integrated on the table

Power consumption

Power consumption standard

3.24W while in use

LED light :1.8W

Fans in total: 1.44W

0.75W standby power consumption or up on request

Power consumption option

LED light: LED brightness adjustment options

Fans in total: up to14.4W

Input:

110-240VAC, 10A, 50/60Hz

Outlets

Regular table:

Power socket + optional LAN cable (extra cost)

Output values

Output VAC (power socket):

100–240 VAC, 8 A, 50–60 Hz

Output USB charging:

USB Type A socket, Type C option, Maximum combined output 18 W

Air Ventilation

Air Ventilation Ventilation rate:

More than 1m³/ minute standard

Adjustable higher ventilation options

Acoustic performance

For speech level reduction (D_S,A) and Noise isolation class (NIC), third party test reports are available per request

Certificates

dancoo 2F

Packaging and transportatinon

Net weight (kg)

620

Gross weight (kg)

723

UNIT/20GP

UNIT/40GP

UNIT/40HQ

Packaging size

2270×930×1330mm

+900×900×1100mm

Feature

Exterior

Powder coated steel

Glass (door & rear)

Enamelled glass

Frame and table

Enamelled glass attached+laminate on birch plywood

Solid walls, roof and floor

A sandwich element of sheet metal, birch plywood, recycled acoustic foam and acoustic felt.

An anti-static and stain resistant low loop pile carpet for interior floor.

Weight

620.3

Measurements

Exterior (height, width, depth)

220×200×125cm

Interior (height, width, depth)

200×180×122cm

Door (height, width)

220×100cm

Table (width, depth, height)

70×38×64cm

Power consumption

Power consumption standard

6.48W while in use

LED light :3.6W

Fans in total: 2.88W

0.75W standby power consumption or up on request

Power consumption option

ED light: LED brightness adjustment options

Fans in total: up to 28.8W

Input:

110-240VAC, 10A, 50/60Hz

Outlets

Regular sofa:

Power socket + optional LAN cable (extra cost)

Output values

Output VAC (power socket):

100–240 VAC, 8 A, 50–60 Hz

Output USB charging:

USB Type A socket, Type C option, Maximum combined output 18 W

Air Ventilation

Air Ventilation Ventilation rate:

More than 2m³/ minute standard

Adjustable higher ventilation options

Acoustic performance

For speech level reduction (D_S,A) and Noise isolation class (NIC), third party test reports are available per request

Certificates

dancoo 2F2

Packaging and transportatinon

Net weight (kg)

624

Gross weight (kg)

727

UNIT/20GP

UNIT/40GP

UNIT/40HQ

Packaging size

2270×1210×1330mm

+900×900×1100mm

Feature

Exterior

Powder coated steel

Glass (door & rear)

Enamelled glass

Frame and table

Enamelled glass attached+laminate on birch plywood

Solid walls, roof and floor

A sandwich element of sheet metal, birch plywood, recycled acoustic foam and acoustic felt.

An anti-static and stain resistant low loop pile carpet for interior floor.

Weight

623.6

Measurements

Exterior (height, width, depth)

220×220×123.6cm

Interior (height, width, depth)

200×200×120cm

Door (height, width)

220×84.6cm

Table (width, depth, height)

70×53×64cm

Power consumption

Power consumption standard

6.48W while in use

LED light :3.6W

Fans in total: 2.88W

0.75W standby power consumption or up on request

Power consumption option

ED light: LED brightness adjustment options

Fans in total: up to 28.8W

Input:

110-240VAC, 10A, 50/60Hz

Outlets

Regular sofa:

Power socket + optional LAN cable (extra cost)

Output values

Output VAC (power socket):

100–240 VAC, 8 A, 50–60 Hz

Output USB charging:

USB Type A socket, Type C option, Maximum combined output 18 W

Air Ventilation

Air Ventilation Ventilation rate:

More than 2m³/ minute standard

Adjustable higher ventilation options

Acoustic performance

For speech level reduction (D_S,A) and Noise isolation class (NIC), third party test reports are available per request

Certificates

dancoo 4F2

Packaging and transportatinon

Net weight (kg)

1110

Gross weight (kg)

1280

UNIT/20GP

UNIT/40GP

UNIT/40HQ

Packaging size

2470×1000×1350mm×2

Feature

Exterior

Powder coated steel

Glass (door & rear)

Enamelled glass

Frame

Enamelled glass attached

Solid walls, roof and floor

A sandwich element of sheet metal, birch plywood, recycled acoustic foam and acoustic felt.

An anti-static and stain resistant low loop pile carpet for interior floor.

Weight

800

Measurements

Exterior (height, width, depth)

220×220×243.6cm

Interior (height, width, depth)

200×200×237.2cm

Door (height, width)

220×84.6cm

Table (width, depth, height)

Power consumption

Power consumption standard

12.96W while in use

LED light:7.2W

Fans in total: 5.76W

0.75W standby power consumption or up on request

Power consumption option

ED light: LED brightness adjustment options

Fans in total: up to 57.6W

Input:

110-240VAC, 10A, 50/60Hz

Outlets

Regular wall or floor:

Power socket + optional LAN cable (extra cost)

Output values

Output VAC (power socket):

100–240 VAC, 8 A, 50–60 Hz

Output USB charging:

USB Type A socket, Type C option, Maximum combined output 18 W

Air Ventilation

Air Ventilation Ventilation rate:

More than 4m³/ minute standard

Adjustable higher ventilation options

Acoustic performance

For speech level reduction (D_S,A) and Noise isolation class (NIC), third party test reports are available per request
